Slab Bolster – Plastic frame support

Accessories - Iron workers, Accessories - Iron workers

Visit Slab Bolsters can be used to support a large area of wire mesh or reinforcement. Visit Slab Bolster sold by the foot or to your specifications.

Height: 0.75, 1.25 and 1 to 3 inches in 0.5-inch increments
Suitable for all rebar size

Model

Delivery type

Clear

Add to quote

Description
Made of resistant polyethylene, its longitudinal shape makes it quick and easy to install steel studs. In addition, the lugs at the base of the Slab Bolsters from Plasti-Tom are designed to leave no marks when the formwork is removed. This product ensures optimum concrete flow, helping to prevent voids or linear cracks.

Shipped in 48-inch sections, the Slab Bolsters are often used with our metal tower and chair products. They are used to support a first or second row of frames on your top slabs.

Table of available models

Product	Thickness	Quantity per bag	Quantity per pallet
ECHEL-075	0.75" (19 mm)	96 parts/bag	7,392 parts/pallet
ECHEL-100	1" (25 mm)	96 parts/bag	6,720 parts/pallet
ECHEL-125	1.25" (32 mm)	96 parts/bag	6,720 parts/pallet
ECHEL-150	1.5" (38 mm)	96 parts/bag	6,720 parts/pallet
ECHEL-200	2" (52 mm)	72 partsbag	4,536 parts/pallet
ECHEL-250	2.5" (63 mm)	72 parts/bag	3,528 parts/pallet
ECHEL-300	3" (76 mm)	72 parts/bag	3,024 parts/pallet

Further information

Thickness

Épaisseur: 0,75 po (19 mm), Épaisseur: 0,75 po (19 mm), Épaisseur: 1 po (25 mm), Épaisseur: 1 po (25 mm), Épaisseur: 1,25 po (32 mm), Épaisseur: 1,25 po (32 mm), Épaisseur: 1,5 po (38 mm), Épaisseur: 1,5 po (38 mm), Épaisseur: 1,75 po (45 mm), Épaisseur: 1,75 po (45 mm), Épaisseur: 2 po (52 mm), Épaisseur: 2 po (52 mm), Épaisseur: 2,25 po (57 mm), Épaisseur: 2,25 po (57 mm), Épaisseur: 2,5 po (63 mm), Épaisseur: 2,5 po (63 mm), Épaisseur: 3 po (76 mm), Épaisseur: 3 po (76 mm)
